| Our company's CNC vertical honing machine has the characteristics of high precision, high efficiency, wide applicability,simple operation,small footprint,etc.,can enable you to achieve good dimensional accuracy, surface roughness, roundness, straightness, improve your processing efficiency, reduce your production costs,and make your products more competitive. | |||||||||
This machine tool is mainly used for honing and processing various cylinder liner holes and other precision holes.
Advanced design and reliable performance: all use imported servo systems and CNC control, and servo motors are used for spindle rotation; machine tool strokes are synchronous servo motors and electronic drives, with high positioning accuracy.
The new VHM series CNC vertical deep hole honing machine is one of the most advanced vertical honing machines on the market,with the following features:
1. Suitable for precision inner hole processing fields such as hydraulic pneumatic, aviation, aerospace, automobile, and motorcycle industries.
2. Using servo control technology, it can achieve the requirements of dimensional accuracy IT5, surface roughness Ra0.1, roundness 0.0005mm, cylindricality 0.001mm/50mm, and the accuracy of the inclusion angle of the mesh.
3. The bed and columns adopt a steel plate burst-connecting structure with reinforced steel, and adopts a second annealing treatment, which has a stable and reliable structure and strong stability.
4. Programmable stroke control and machining cycle time control ensure that each workpiece has the same processing time and the results are consistent during mass production. Optimize abrasive performance through automatic feeding speed to ensure consistency between processing results and processing efficiency.
5. The machining efficiency of vertical deep-hole honing machines is much higher than that of internal circle grinders and other internal hole finishing equipment, and can reach 4-6 times that of internal circle honing process, greatly improving processing efficiency. In addition, better pore geometry and cross-mesh surfaces that act as oil film lubrication are also available.
6. Using imported brand NC system, a special honing control software HMI has been developed, which has a more vivid interface and is convenient to operate.
This machine tool is mainly used for honing and processing various cylinder liner holes and other precision holes.
Advanced design and reliable performance: all use imported servo systems and CNC control, and servo motors are used for spindle rotation; machine tool strokes are synchronous servo motors and electronic drives, with high positioning accuracy.
The new VHM series CNC vertical deep hole honing machine is one of the most advanced vertical honing machines on the market,with the following features:
1. Suitable for precision inner hole processing fields such as hydraulic pneumatic, aviation, aerospace, automobile, and motorcycle industries.
2. Using servo control technology, it can achieve the requirements of dimensional accuracy IT5, surface roughness Ra0.1, roundness 0.0005mm, cylindricality 0.001mm/50mm, and the accuracy of the inclusion angle of the mesh.
3. The bed and columns adopt a steel plate burst-connecting structure with reinforced steel, and adopts a second annealing treatment, which has a stable and reliable structure and strong stability.
4. Programmable stroke control and machining cycle time control ensure that each workpiece has the same processing time and the results are consistent during mass production. Optimize abrasive performance through automatic feeding speed to ensure consistency between processing results and processing efficiency.
5. The machining efficiency of vertical deep-hole honing machines is much higher than that of internal circle grinders and other internal hole finishing equipment, and can reach 4-6 times that of internal circle honing process, greatly improving processing efficiency. In addition, better pore geometry and cross-mesh surfaces that act as oil film lubrication are also available.
6. Using imported brand NC system, a special honing control software HMI has been developed, which has a more vivid interface and is convenient to operate.
